BA-EST/CV fingers vibrating wire strain gauge are used to measure the stress states existing structures or to monitor tensions existing in the ribs, during the excavation of the tunnels. Such control is necessary for the verification of the stress and supporting structures strain both temporary and permanent.
The load limiters "M/G FX" series are extremely small and easy to handle, with aluminum load cell body with high protection degree (IP 67) for application in any environment. "M/G FX" applied to the fixed head rope and the simple installation procedure takes only a few minutes.
The new GD4VIS and ME1VIS compression load cells have the ability to view directly on the load cell the value of the applied load. Through a built-in indicator load cell is capable to display applied load, set filters, set the peak and linearize load points.
Steel frame powder coated (optional) stainless steel.
Fixing elements in AISI 316 stainless steel
Load Cell Pin to Pin & 17.4PH steel and stainless steel
Pulleys hardened steel (standard) or stainless steel 17.4 PH (optional)
Self-lubricating ball bearings, working temperature from -20 ° Work to +70 ° C.
Output Signal:
The load limiters Series M/G LC are applied to fixed rope with a simple operation.
The series covers a comprehensive range of standard applications up to 20,000 kg on the roll of rope with one or two thresholds.
Different applications models are realized upon specific request with multiple thresholds and higher flow rates.
The basic models are powder coated and galvanized parts and outdoors installation or models particularly exposed to corrosive agents are entirely made of stainless steel and with explosion-proof limit switch.
You can find them in the Weighing catalog, Special Applications section, or you can go directly to the detail page by clicking on this link
